Gold Nanomaterials: Functionalized Nanogold®

Choose your solubility! Hydrophilic, amphiphilic, or hydrophobic nano materials, 3 or 5 nm functionalized gold nanoparticle labels.

Nanoparticle Size: 3 nm, 5 nm
Reactive Groups: Amphiphilic, Hydrophilic, Hydrophobic
Unit Sizes: 80 mg

Gold Nanomaterials: Functionalized Nanogold®

Choose your solubility! Hydrophilic, amphiphilic, or hydrophobic nano materials, 3 or 5 nm functionalized gold nanoparticle labels.

Nanoparticle Size: 3 nm, 5 nm
Reactive Groups: Amphiphilic, Hydrophilic, Hydrophobic
Unit Sizes: 80 mg
SKU
Description
Price
  • 3012-80MG

Nanoparticle Size: 5 nm, Reactive Group: Amphiphilic

$ 490.00

  • 3013-80MG

Nanoparticle Size: 5 nm, Reactive Group: Hydrophilic

$ 490.00

  • 3014-80MG

Nanoparticle Size: 5 nm, Reactive Group: Hydrophobic

$ 428.00

  • 3015-80MG

Nanoparticle Size: 3 nm, Reactive Group: Hydrophobic

$ 519.00

Grow the size - Keep the precision

Combine nanoparticle developers with Nanogold® labels

Easy, archival developers for any scope or blots
  • GoldEnhance™:
    Simple. Superior. Precision nanoparticle enhancement
    Sharp, archival staining of blots or easy viewing in any scope.
  • Silver Enhancement:
    Precision nanoparticles, not colloidal silver blobs: precise development for any scope.

Gold Nanomaterials: Functionalized Nanogold®

Choose your solubility

5 nm and 3 nm functionalized gold nanoparticles, in the solubility of your choice:

  • hydrophilic

  • hydrophobic

  • amphiphilic

These nanoparticles are coated and stabilized using different thiol ligands capped by chemical groups which provide a variety of solubilities, and these gold nanomaterials are therefore suitable for a wide range of applications in different systems and environments.

The octane- and dodecanethiol functionalized gold nanoparticles have great solubility in organic solvent such as toluene, while the hydrophilic (1-mercaptoundec-11-yl) tetraethyleneglycol functionalized gold nanoparticles dissolve in water and alcohols. The 1-mercapto-(triethyleneglycol) methyl ester functionalized gold nanoparticles are amphiphilic, dissolving in a wide variety of solvents including toluene, chloroform, ethyl acetate, acetone, water and alcohols.

Features of Gold Nanomaterials

  • Solubility properties tailored to your application.
  • Specification sheet gives mean size and size distribution for each lot.
  • Stable and chemically inert.

Applications

  • Preparation of nanocomposites and nanostructured materials.
  • Fiducial markers for high-resolution electron microscopic tomography applications.
  • Markers for surfaces, structures and materials with complementary properties.
3-5 nm (1-mercaptounde-11-yl) tetraethyleneglycol functionalized gold (mean core diameter 4.74 ± 0.73 nm).

3-5 nm (1-mercaptounde-11-yl) tetraethyleneglycol functionalized gold (mean core diameter 4.74 ± 0.73 nm).

3-5 nm dodecanethiol functionalized gold (mean core diameter 4.08 ± 0.76 nm).

3-5 nm dodecanethiol functionalized gold
(mean core diameter 4.08 ± 0.76 nm).

Amphiphilic

Gold Nanoparticles

3012 1-Mercapto-(triethylene glycol) methyl ether functionalized 5 nm gold nanoparticles The thiol is covalently attached to 5 nm gold nanoparticles. Soluble in a variety of solvents including toluene, chloroform, ethyl acetate, acetone, water and alcohols.

3012

1-Mercapto-(triethylene glycol) methyl ether functionalized 5 nm gold nanoparticles

The thiol is covalently attached to 5 nm gold nanoparticles. Soluble in a variety of solvents including toluene, chloroform, ethyl acetate, acetone, water and alcohols.

Hydrophilic

Gold Nanoparticles

3013 (1-Mercaptoundec-11-yl) tetraethyleneglycol functionalized 5 nm gold nanoparticles The thiol is covalently attached to 5 nm gold nanoparticles. Soluble in alcohol and water.

3013

(1-Mercaptoundec-11-yl) tetraethyleneglycol functionalized 5 nm gold nanoparticles

The thiol is covalently attached to 5 nm gold nanoparticles. Soluble in alcohol and water.

Hydrophobic

Gold Nanoparticles

3014

Dodecanethiol functionalized 5 nm gold nanoparticles

The thiol is covalently attached to 5 nm gold nanoparticles. Use in organic solvents such as toluene.

3014 Dodecanethiol functionalized 5 nm gold nanoparticles The thiol is covalently attached to 5 nm gold nanoparticles. Use in organic solvents such as toluene.

3015

Octanethiol functionalized 3 nm gold nanoparticles

The thiol is covalently attached to 3 nm gold nanoparticles. Use in organic solvents such as toluene.

3015 Octanethiol functionalized 3 nm gold nanoparticles The thiol is covalently attached to 3 nm gold nanoparticles. Use in organic solvents such as toluene.
